    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy

    Ask Lasest Price
    Brand Name : STH, TIANHE
    Model Number : SLB-160
    Certification : CE, ISO, GMP
    Price : Negotiation
    Delivery Time : 30 - 45 days
    • Product Details
    • Company Profile

    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy

    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy


    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy Quick Details:


    1. PLC & Touch Screen Control

    2. meet ISO, CE, GMP requirement


    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy Application

    It is designed with success to meet the needs in the market by our own research fellows. It has PLC Human interface, frequency converter, higher automation, easy operation, beautiful style, full function, well performance and durability. It conforms to "GMP" standards.


    Automatic Double Aluminum Paper Striping Packing Machine For Capsule Pill Candy Features:


    1. Vibration feeder and crisp remover can effectively remove the powder and crisps inside medicine.
    2. Auto counting, horizontal perforation, slitting, waster-side cutting, printing batch number and auto punch etc functions can be achieved automatically in one process.
    3. The diameter of heat pressing cam can be changed from 110 to 140 mm.
    4. The rotation speed of the material controlling cam is equal to heat pressing cam, and the cams equilibrium is equal to medicament nest of heat pressing cam. Therefore it can have the distance from the plate edge the medicament nest and the one between the central medicament nest be equal.
    5. The punch adopts electronic checking signal and PLC programs. It can change the number of granules at any time in the horizontal direction of the plate, making the user free to change the plates without replacing the moulds.


    Technical Parameters:


    Speed of drum (rpm)7-15 stepless
    Max. Packing Width (mm)165mm
    PVC for Medicine(mm)0.15-0.1×160
    AL/PL Complex Film(mm)0.08×160
    Hole die of Reel (mm)40-45
    Electrothermal Power1kw×2
    Main Motor (kw)0.55
    Air Pressure (Mpa)0.4
    Air supply≥0.1m³/min
    Overall Dimensions(mm)1450×600×1670(L×W×H)
    Weight (kg)600



    Our services

    Installing and Commission:

    We will install and test the machine in best working condition before shipment. If customer requires our technician to adjusting the machine and train technician at arrival place, we will send technician there. All our expenses including round-trip air ticket to the nearest airport, local conveyance to your factory, Lodging&Boarding expenses shall be payable by you. In case the stay of our technician, additional service fee will be charged .


    Warranty period:

    One year for fully machine guarantee. And in this year if the machine broken caused by mechanical problem, all of the spare part is free. The service of the machine all though the machine’s life.
