    ZPW500 Series Rotary Ring Shape Tablet Press Machine 48600pcs/H

    Ask Lasest Price
    Brand Name : TIAN HE
    Model Number : ZPW500 Series
    Certification : ISO
    Supply Ability : 50 Set /Sets Per Year
    Delivery Time : About 25 working days after payment
    Price : Negotiation
    • Product Details
    • Company Profile

    ZPW500 Series Rotary Ring Shape Tablet Press Machine 48600pcs/H

    Automatic Tablet Press Machine ZPW500 Series Multi-functional Rotary Tablet Press Double-color Tablet Ring Shape Tablet Press Machine


    Application


    It is a new type double-sided multi-functional tablet press machine, which can press hard-forming raw material into big size tablets, such as milk tablets, effervescent tablet, calcium tablet, dishwashing tablet, salt tablet, ect.

    This machine can produce round shape tablet, ring shape tablet and double-layer tablet.

    It is mainly used in pharmaceutical, chemistry, foodstuff, electronic industries.


    Features


    • PLC and touch screen control, all the running parameters can be set and shown.
    • Adopt double-sided structure, high output and high pressure
    • Install the pressure sensor inside the pressure roller shaft, show the actual working pressure in touch screen.
    • Adopt planar double-enveloping worm gear technology, large load and high stable
    • Automatic oil&grease central lubrication system, ensure the lubrication of pressure rollers, tooling and tracks, extending the working life of the machine.
    • Adopt electromagnetic clutch device, improve machine starting torque
    • After some change, this machine can also make double-color tablets (optional)
    • After some change, this machine can also adopt force-feeder device (optional)

    Technical Parameter:


    ModelZPW-27ZPW-33ZPW-41
    Number of Stations273341
    Max Main Pressure (KN)150150150
    Max Tablet Diameter (mm)403020
    Max Filling Depth (mm)353535
    Max Tablet Thickness (mm)141414
    Max Turret Speed (r/min)152528
    Max Production Capacity (pcs/h)4860099000138000
    Motor Power (kw)151313
    Overall Size (mm)1360×1050×1848
    Machine Weight (kg)3800
