Mechanical&Electrical Integration Core-covered Tablet
Compression Machine Extended-release Pill Tablet Press Machine
Core-covered Tablet Press Machine
Application
The core covered tablet is a novel form of tablet emerging in the
world in recent years.
Model ZPW20 Rotary Covered Tablet Press is an electronic enhanced
integrated product
developed by this company on the basis of absorption and digestion
of the international
advanced technologies. It is also the first covered tablet press
produced in our country,
filling a domestic blank in this area.
Features
1. It adopts a fully enclosed structure with the operation
compartment isolated from
the outside. Ensuring the cleanness in the tablet compressing area
without creation of
cross contamination with the outside. The compressing compartment
is wholly made of
stainless steel, which is in compliance with the GMP requirement on
the production of
pharmaceuticals.
2. The machine adopts the adjustment of speed by means of frequency
inversion
which is easy in operation and wide in the scope of adjustment of
speed. Disintegrated
structure is adopted for the turret, with the top of the table
directly in contact with the
pharmaceutical materials made of stainless steel and hardened by
special technological
process, resulting in the remarkable improvement in fatness and
resistance to wearing.
3. The lubrication system of this machine can ensure the oil supply
to every
lubricating point, reducing the wearing of the worm-gear box and
the tracks and extending
the working life of the machine.
4. The electrical part adopts programmable control, with multi
automatic control
functions such as stopping of the machine on overload,
insufficiency in the core material
hopper ect. It has a double detection mechanism by photo-electric
switch and pressure
sensor, to ensure the automatic rejecting of any tablet without a
core.
5. This machine can be used as a normal tablet press or for the
production of double
layer tablets after a slight alteration. When used to produce the
covered tablets, attention
should be drawn to the hardness and the precision of the dimension
of the core tablet.
6. ZPW26 model is a new upgraded product on the basis of ZPW20
machine.
Technical Parameter:
| Model | ZPW26 |
| NO. of stations | 26 |
| Max main pressure(KN) | 80 |
| Max tablet diameter (normal tablet) (mm) | 18 |
| Max tablet diameter(core-covered tablet) (mm) | 12 |
| Max filling depth (mm) | 18 |
| Max tablet thickness (mm) | 8 |
| Core tablet size | Max diameter (mm) | 10 |
| Max thickness(mm) | 5 |
| Max turret speed (normal tablet) (r/min) | 36 |
| Max turret speed (core-covered tablet) (r/min) | 14 |
| Max production capacity (normal tablet) (pcs/h) | 56160 |
| Max production capacity (core-covered tablet) (pcs/h) | 21840 |
| Motor power(kw) | 4 |
| Overall size (mm) | 920*970*1900 |
| Machine weight(kg) | 1600 |
