Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press

    Buy cheap Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press from wholesalers

    Buy cheap Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press from wholesalers
    • Buy cheap Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press from wholesalers

    Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press

    Ask Lasest Price
    Brand Name : STH, TIANHE
    Model Number : ZP5/7/9 series
    Certification : CE, ISO, GMP
    Price : Negotiation
    Payment Terms : L/C, T/T
    Supply Ability : 500 sets per month
    Delivery Time : 15 - 30 days
    • Product Details
    • Company Profile

    Rotary Tablet Press Pill Machine For Pharmaceutical Use , Tablet Punch Press

    Rotary Tablet Press Pill Machine For Pharmaceutical Use


    Rotary Tablet Press Pill Machine For Pharmaceutical Use Quick Details


    - Number of stations: 5/7/9

    - Max main pressure: 40/60KN

    - Max tablet diameter: 13/20mm

    - Max production capacity: 12000 pcs/hour

    - Main motor: 1.5/2.2kw

    - Machine Weight: 350kgs


    Tablet Press Pill Machine Applications:


    ZP5/7/9 series rotary tablet press is a continuously rotating tableting machine developed by our company. It compresses granular raw materials into various ordinary and shaped pieces, mainly used in tablet production in the pharmaceutical industry. It is also suitable for chemical, food, electronics, plastics, powder metallurgy and other industrial sectors.

    Tablet Press Pill MachineStructural Features:


    1. GMP-compliant design
    2. High quality stainless steel construction
    3. Overall tight sealing and dustproof design
    4. High-definition, isolated window design for easy disassembly, maintainability.


    Tablet Press Pill Machine Main Technical Specifications


    ModelZP5A/BZP7A/BZP9A/B
    Number of Stations579
    Max main pressure (kN)40/6040/6040/60
    Max Tablet Diameter (mm)13/2013/2013/20
    Max Filling Depth (mm)151515
    Max Tablet Thickness (mm)666
    Max Turret Speed (r/min)252525
    Max Production Capacity (pcs/h)75001050012000
    Motor Power (kW)1.5/2.2
    Overall Size (mm)660*480*1050
    Machine Weight (kg)350

    Tablet Press Pill Machine Details



    Tablet Press Pill Machine fianl products
