    Stainless Steel Turret High Speed Powder Pressing Machine 25mm

    Ask Lasest Price
    Brand Name : STH, TIANHE
    Model Number : GZP-51
    Certification : GMP
    Price : Negotiation
    Delivery Time : 30 - 45 days
    • Product Details
    • Company Profile

    Stainless Steel Turret High Speed Powder Pressing Machine 25mm

    Stainless Steel Turret Auto Feeding High Speed Powder Pressing Machine 25mm


    Stainless Steel Turret Auto Feeding High Speed Powder Pressing Machine 25mm

    - Max main pressure: 100KN

    - Pre-pressure: 40KN

    - Control system: automatic electrical system with touch screen & PLC

    - Tooling standrad: EU-Tooling

    - Motor: 7.5kw

    - Feeding type: force feeder device


    Stainless Steel Turret Auto Feeding High Speed Powder Pressing Machine 25mm Feature:

    • High speed with large quantity punches, double press rollers, suitable for mass production.
    • Made of stainless steel, the housing is fully closed. The surface of the rotary turret is covered with a hardened layer so that the turret surface is wear resistant. The machine conforms to GMP requirements.
    • Perfect tableting system, twice compression forming, reasonable framework with proper space and big pressure roller, machine performance is reliable and no tablet weight difference.
    • Automatic adjust each operation parameter (main pressure, pre-pressure and filling depth) easily without handwheel.
    • Double impeller type force feeder, improve granules flow-ability and filling performance, ensure the filling precision.
    • Tooling track adopt double-side lifting structure, the punches are balanced stress and wear resistance.
    • High performance electrical control system, ensure each program processing precisely.
    • Automatic oil&grease central lubrication system, ensure the lubrication of pressure rollers, toolings and tracks, extending the working life of the machine.
    • Special oil proof, dust proof and noise proof design.

    Technical Parameter:


    ModelGZP-41GZP-51GZP-61GZP-65
    Number of Stations41516165
    Tooling StandardDBBBBBS
    Max Main Pressure (KN)100
    Max Pre-pressure (KN)40
    Max Tablet Diameter (mm)Round tablet25181311
    Irregular tablet25191613
    Max Filling Depth (mm)20181515
    Max Tablet Thickness (mm)10866
    Max Turret Speed (r/min)60
    Max Production Capacity (pcs/h)295200367200439200468000
    Motor Power (kw)7.5
    Overall Size (mm)1420×1200×1850
    Machine Weight (kg)3500

    Appearance for High Speed D Tooling Tablet Press Machine


    Sample we produce (It can be customized)



    Services & FAQ

    One-year warranty period for whole machine except of tubes and human factors etc, and 12-month of after-sale service from the date when you receive machine or 12 months when installation finished;
    Consultant services for whole machine life, and 24 hours technical support by email;
    UPS, English software, user manual and the installation & debugging by our experienced technicians.


    1. Can your machine meet our need well?
    We will supply you a proposal as to your specific requirement, and each machine is customized to satisfy customer's need well.
    2. Are you a factory or a trading company?
    We are the manufacturer, and have been in industry for more than 30 years.
    3. What's your payment way?
    T/T by our bank account directly, L/C, or by the West Union, or in cash.
    4. How can you ensure the machine's quality after we put the order?
    Before the delivery, we will send you machine's pictures and videos, or you can come to us to have the quality checking by yourself, or by the third party inspection organization contacted by your side.
